Name: Mobile Phones Barcode Scanner 2d BT Back Clip with Iphones Barcode Scanner for Point of Sale System
Brand: Guangzhou Luckydoor Electronic & Equipment Co., Ltd.
Availability: InStock

Home Products Portable Wireless Barcode Scanner

Mobile Phones Barcode Scanner 2d BT Back Clip with Iphones Barcode Scanner for Point of Sale System

Product Details:

Place of Origin:	Guangdong, China (Mainland)
Brand Name:	Luckydoor

Contact Now

Detailed Product Description

Private Mold:	NO	Products Status:	Stock
Type:	Barcode Scanner	Scan Element Type:	CMOS
Colour Depth:	32 Bit	Interface Type:	Usb, COM
Max Paper Size:	A4 Size	Optical Resolution:	3mil
Scan Speed:	25inch/63cm Per Second	Warranty(year):	2-Year
After-sales Service:	Return And Replacement, Others, Repair, Free Spare Parts, Onsite Training And Inspection, Call Center And On-line Technical Support	Software Development Kit (sdk):	NO
Color:	Black	Product Name:	Phone Back-Clip Portable Barcode Scanner
Light Source:	617nm LED Aimer, White LED	Housing Material:	ABS+PC
Interface:	Receiver: USB-HID, Bluetooth: HID, BLE, SPP	Function:	Bar Code Reading
Scan Mode:	Auto Sense	Scanning Method:	Antomatic
Feature:	Fast Scanning, Smart	Application:	Logistics Industry, Warehouse

Product Description

Wireless Barcode Scanner Bluetooth 1d 2d Qr Code Phone Back Clip Android Bar Code Reader Handheld Barcode Reader

Luckydoor K-20 is a brand new series of ATEK which belong to high-end products of Syble, excellent stability and quality
assurance.compatible with 99% mobile phones.press and hold for 5s to enter the pairing state.clonnect the scanner when you hear a beep,the pairing is successful.plug and play,no driver installation needed.experience the power of a long-lasting battery.

Product Features

1.Can interpret all kinds of 1D/2D code, direct Chinese 2D code
2.Support Android/iOS system, can replace PDA, scanning gun, mobile phone scanning
3.512000 characters can be stored in offline/inventory storage mode
4.Bluetooth connection, easy and fast
5.Wireless Bluetooth empty 50-100 meters

Specification

Light Sources	White LED lighting when decoding, gradient lighting with distance. Laser cross indication
Supported Symbologies	1D: Code 128, EAN-13, EAN-8, UPC-E, UPC-A, ISBN, ISSN, Code 11, ITF-25(Interleave 2 of 5), Code 39, Code 93, Code 32, CodaBar, Matrix 2 of 5, Industrial 25, IATA25, MSI-Plessey. 2D: QR Code, Micro QR, Data Matrix, PDF417, Micro PDF417, Aztec.
Scan Angle	Yaw45°, Rotaion 360°, Pitch45°
Contrast	≥20%
Resolution	640*480
Scan Mode	Manual/Continuous/Automatic Scintillation
Precision	≥3mil
Field Angle	42°(H) x 28°(V)
Depth of Scan Field	EAN-13(13mil):4-55mm
Error Rate	1/5million
Interface	Receiver: USB-HID, Bluetooth: HID, BLE, SPP
Communication Mode	Paired dedicated receiver: 2.4g communication; Paired mobile bluetooth devices: Dual-mode Bluetooth
Transmission Distance	100M(Open Yard)
Pairing Mode	1, through the bar code pairing 2,special pairing button
Prompt Function	1, power prompt 2, connection prompt
Pairing Mode	One to One: One Scanner Pairs One Receiver, One scanner paired with a Bluetooth mobile device.
Receiver	Dedicated Bluetooth USB flash drive receiver for Android /IOS mobile devices
Storage Mode	Offline Storage Mode: When the scanner exits the connection range, the data is automatically stored. Storage capacity is 512000 characters. Inventory storage mode: Scanner can enter inventory mode, storage capacity is 512000 characters.
Dimension	69mm36mm153mm
Weight	1M straight
Material	ABS+PC
Operating Temperature	-20℃~55℃
Storage Temperature	-40℃~70℃
Humidity	0%~95%(Non-condensing)
Drop Resistance	Withstands multiple 1.5 meters drops to concrete
Voltage	DC 5V±5%
Lithium battery	3000mA
Charging Time	3-4.5h
Battery Working Time	12h
Operating Current	when not scanning code ≥26mA; when scanning code ≥300mA
Standby Current	0mA(Standby is to cut off battery power)
Charging Model	TypeC USB charging cable, plug-in direct charging

Details Images

Application

Product Advantage:

• Widely use in different application like warehouse,retail stores
• Long wireless transmission distance
• Supports 2.4G wireless,Bluetooth connection and USB wired connection

Packaging Details：Package Contents

1* barcode scanner
1* stand(optional)
1* User Manual (English version)
1* Cable (1.8m)
1* Warranty card
Syble barcode scanner standard package

Related Products

1D handheld wired laser barcode scanner

1D / 2D handheld wired barcode scanner

1D / 2D wireless barcode scanner

1D / 2D hands-free desktop barcode scanner

1D / 2D presentation desktop barcode scanner

1D / 2D presentation desktop barcode scanner

Company Profile

FAQ

1, Does this 2d blue tooth mini barcode scanner use usb type C?
Yes, it uses a USB type C for charging and connecting to a PC or notebook

2, How many barcodes can I store into this wireless blue tooth mini barcode reader ?
It can store max 35000 barcodes (EAN13)

3, Can I use this portable blue tooth barcode scanner as a wired scanner when the battery run out ?
Yes ,it can use as wired mode

4, What is your company warranty policy on this blue tooth portable barcode scanner ?
We support 2 years warranty on this blue tooth barcode scanner ,extended warranty is available
